Meet Our New LaunchHome LiftsSeries.
Custom Luxury Cabins
Cabin DetailsHC188
HC188
“”
Car DoorHSC00709 champagne gold fantasy metal plate
Front WallHSC00709 champagne gold fantasy metal plate
Side WallsHSC00709 champagne gold fantasy metal plate
Back WallHSC00709 champagne gold fantasy metal plate
HandrailFK-SP63 black gold sand
CeilingGalaxy, black aluminum alloy frame + light strip
FloorPVC
Art Background Walls
HCS501
HCS502
HCS503
HCS504
HCS505
HCS506
HCS510
HPT001
HPT002
HPT003
HPT004
HPT005
HPT006
Premium Customizations
Premium Ceiling Variants
027
HCL027Spiral Nebula Star Map
032
HCL032Stippled Frosted Glass
036
HCL036Warm LED Recessed Panel
Control Panels (COP)
026
HOP026Flush Smart Touch COP
030
HOP030Multimedia Display Panel
036
HOP036Slimline Metal Key COP
038
HOP038Classic Braille Button COP
Technical Parameters
| Model & Structure | Duty Load | Speed | Car Size (CW × CD × CH) | Door Size (OP × OPH) | Shaft Size (HW × HD) | Overhead (OH) | Pit (PP) |
|---|---|---|---|---|---|---|---|
| Concrete / Steel Shaft Parameters | |||||||
| GEH160 (Concrete/Steel) | 400 kg | 0.4 m/s | 1000 × 1080 × 2200 mm | 700 × 2000 mm | 1500 × 1330 mm | 2850 mm | 250 mm |
| GEH320S (Concrete/Steel) | 400 kg | 0.4 m/s | 1200 × 1280 × 2200 mm | 700 × 2000 mm | 1750 × 1500 mm | 2850 mm | 250 mm |
| Aluminum Shaft Parameters | |||||||
| GEH160 (Aluminum) | 400 kg | 0.4 m/s | 1000 × 1080 × 2200 mm | 700 × 2000 mm | 1650 × 1480 mm | 2850 mm | 250 mm |
| GEH320S (Aluminum) | 400 kg | 0.4 m/s | 1200 × 1280 × 2200 mm | 700 × 2000 mm | 1900 × 1650 mm | 2850 mm | 250 mm |
| SLP500 (Aluminum) | 350 kg | 0.3 m/s | 1200 × 950 × 2200 mm | 800 × 2000 mm | 1315 × 1450 mm | 2500 mm | 100 mm |
